Van Dam CM 608 M

Van Dam has split up the CM 608 M printing machine in modules like; printing unit, in-feed, take-off etc (modular building concept). The advantage of this concept is that the customer can compose the machine according to his requirements.

After composing the machine configuration, it can be extended with a variety of options to shorten the change over time. To enhance printing quality and to reduce scrap and solvent usage. It’s also possible to trade-in and upgrade the old-configuration to new modules. The result is a flexible workhorse with a stable high performance level.

Machine Features

Up to 8 colors
Wide range of products (diameter 50-230 mm)
Production speed up to 600 cups per minute
High printing quality
Modular building concept
Reliable and proven technology
Operator friendly

Specifications

Brand	Van Dam
Model	CM 608 M
Year of build (YOB)	2004
Condition	n/a
Speed / cups per minute	600
Speed / cups per hour	36.000
Cup height / minimum	30 mm
Cup height / maximum	200 mm
Rim diameter / minimum	Ø 50 mm
Rim diameter / maximum	Ø 230 mm
Length / maximum	120° – 474 mm, 135° – 420 mm, 150° – 368 mm
Printing format length	540 mm 3 blanket mode pin bar, 610 mm 3 blamket mode magnetic
Taper / minimum	0
Taper / maximum	12°
Colours	currently equipped with 8 units
Dupatech reference	B-25027
