Polytype BDM 482
Polytype BDM 482. Year of build 2014. In LIKE NEW condition
Automatic cups loading system. Automatic stacking system with cups counting system and stack separation.
Specifications
| Brand | Polytype |
|---|---|
| Model | BDM 482 |
| Year of build (YOB) | 2014 |
| Condition | like new |
| Speed / cups per minute | 450 |
| Speed / cups per hour | 27.000 |
| Cup height / minimum | 30 mm |
| Cup height / maximum | 200 mm |
| Rim diameter / minimum | ø 60 mm |
| Rim diameter / maximum | ø 185 mm |
| Printing width / maximum | 145 mm |
| Length / maximum | 200 mm |
| Printing format length | 345 mm in 6 segment mode, 502 mm in 3 segment mode |
| Taper / minimum | 2° |
| Taper / maximum | 15° |
| Colours | 6 (possibility to install maximum 8 units) |
| Total power | 40 Kva |
| Pressure | 6 – 10 bar |
| Dupatech reference | B-25005 |
